Tianjin Brisk Metalwork Co., Ltd. is one of the leading manufacturers and suppliers of s420 square hollow section for high strength steel structures in China. We have world-leading production equipment and strong manufacturing capabilities. Please feel free to buy bulk durable s420 square hollow section for high strength steel structures from our factory.
Which S420 Route Do We Offer for Square Hollow Sections?
| Grade | Standard | Condition | Choose it when |
|---|---|---|---|
| S420MH | EN 10219-1 | Cold-formed, welded, thermomechanically rolled coil | You want lighter sections and efficient welded fabrication |
| S420NH | EN 10210-1 | Hot-finished, normalized | Your members will be hot-bent, galvanized, or form heavy nodes |
Both routes share the same SHS geometry. If you are unsure, tell us the fabrication steps after delivery and we will match the route to them.
Why Does the Square Shape Suit High-Strength Steel Structures?
- Equal stiffness on both axes: a column does not have a weak direction, so S420 strength is used in both.
- Closed section: it resists torsion well, which suits canopies, crane frames and exposed members.
- Flat faces: beams, plates and bracing land on a flat face, so connection details are straightforward.
- Small surface for its capacity: less area to paint or galvanize per tonne than an open section.
Which Dimensions Do We Control So SHS Fits on Your Shop Floor?
A section that meets the standard on paper can still cause trouble at fit-up. We watch these five:
- Wall thickness: the standard permits a negative deviation, and a thin wall means lower capacity than you designed. We roll to nominal and measure the wall on inspection.
- Squareness: faces stay at 90 degrees, which keeps end plates and gussets flush.
- Twist and straightness: checked along the full 12 m length, since twist is what opens gaps in long members.
- Corner radius: kept consistent, because the corner controls joint fit-up in SHS-to-SHS connections.
- End cut: squared ends for members that bear on base plates.
Where Do Fabricators Use S420 Square Hollow Sections?
- Multi-storey and industrial building columns
- Truss chords and web members in long-span roofs
- Canopies, stadium roofs and exposed architectural frames
- Crane structures and lifting frames
- Tower and mast members
How Do We Pack and Protect SHS for Shipping?
- Strapped bundles with dunnage between layers, so corners do not dent
- End protection on painted and galvanized sections
- Marking on every bundle with grade, size, heat and lot
- Container planning: 12 m lengths fit a 40 ft container, and we plan mixed-size loads to make full use of the payload
Real Project Case: When the Wall Was Thinner Than the Drawing
A contractor received 200 x 200 x 10 S420 SHS from another source and measured 9.1 mm on several pieces, about 9 percent under nominal. Across 180 columns (roughly 123 tonnes), that meant less steel capacity than the structural design assumed. They re-sourced from us, we supplied the columns at nominal wall with recorded thickness readings on the inspection report, and the columns were installed without a redesign.
FAQ
Q: Can I order S420 and S355 square hollow sections in the same shipment?
A: Yes. Send both lists and we will plan one load. Each grade is bundled, marked and certified separately, so nothing is mixed up on site.
Q: Can you supply fixed lengths so I do not waste steel cutting 12 m bars?
A: Yes. Tell us the member lengths and the length tolerance you need, and we will cut to those lengths at the mill.
Q: Can you paint or hot-dip galvanize S420 SHS before shipping?
A: Yes. We supply black, painted or hot-dip galvanized sections. For galvanized SHS, tell us if the member is closed so vent and drain holes can be planned with you.
Q: Can I place a trial order before committing to a full project?
A: Yes. Send us the size and quantity you would like to test, and we will confirm what is practical and quote it.
