Tianjin Brisk Metalwork Co., Ltd. is one of the leading manufacturers and suppliers of en 10219 dn 500 lsaw steel pipe in China. We have world-leading production equipment and strong manufacturing capabilities. Please feel free to buy bulk durable en 10219 dn 500 lsaw steel pipe from our factory.
LSAW Pipe for Bridge Structure Support
EN 10219 DN 500 LSAW steel pipe is longitudinal submerged arc welded carbon steel pipe manufactured in compliance with European standard EN 10219, the specification for cold formed welded structural hollow sections for non-alloy and fine grain structural steels.
DN500 corresponds to outer diameter OD 508mm, widely used for heavy structural works. Brisk Steel fabricates EN 10219 DN500 LSAW pipe with S275J0H, S355J2H grades. These pipes are commonly selected for foundation piles, bridge temporary bracing, port structures and building structural support for European, Middle East and Latin America engineering projects.
What is EN 10219 Standard
EN 10219 specifies technical delivery conditions for cold formed welded structural hollow sections. The standard defines chemical composition, mechanical performance, welding requirements, tolerances and impact test requirements for structural steel hollow sections.
- EN 10219-1: Technical delivery conditions
- EN 10219-2: Tolerances on dimensions and cross-section
Commom Grade:
S235JRH- General structural application
- General steel structures
- Framework supports
- Fabrication projects
S275J0H / S275J2H- Higher strength structural steel used for:
- Industrial structures
- Engineering projects
- Load-bearing components
S355J0H / S355J2H: One of the most commonly requested grades for heavy structural applications.
Advantages:
- Higher yield strength
- Better load capacity
- Suitable for demanding structures
Typical applications:
- Bridge structures
- Heavy supports
- Infrastructure projects
EN 10219 DN 500 LSAW Steel Pipe Specifications
| Item | Specification |
|---|---|
| Standard | EN 10219 |
| Product Type | LSAW Structural Steel Pipe |
| Nominal Diameter | DN500 |
| Outside Diameter | Approx. 508 mm |
| Manufacturing Process | Longitudinal Submerged Arc Welding |
| Section Type | Circular Hollow Section |
| Wall Thickness | Customized according to project requirements |
| Length | 6m / 12m or customized |
| End Type | Plain End / Beveled End |
| Surface | Black / Painted / Coated |
| Application | Structural Engineering |
Shipment Details for Brisk Factory
What Quality Inspection
Every batch of EN 10219 DN500 LSAW steel pipe undergoes below inspections before shipment:
- Visual and dimensional inspection (OD, wall thickness, length, straightness)
- Ultrasonic Testing (UT) for longitudinal weld seam
- Radiographic Testing (RT) for critical welds upon request
- Mechanical test: tensile test, yield strength and Charpy V-notch impact test
- Chemical composition analysis
- Coating thickness inspection if anti-corrosion coating required
FAQ
Q: OD 508mm is DN500 EN10219 LSAW pipe?
A: Yes. DN500 nominal diameter LSAW pipe corresponds to outer diameter 508mm, which follows EN 10219 dimension table.
Q: What is difference between S275J0H and S355J2H for EN10219 DN500 LSAW pipe?
A: S355J2H has higher yield strength and requires Charpy impact test at -20℃, used for heavy load or low temperature projects. S275J0H is for regular structural construction with lower cost.
Q: Can you provide 3PE coating on EN 10219 DN500 LSAW pipe?
A: Yes. We can apply 3PE external anti-corrosion coating with controlled micron thickness as your project specification.
Q: Can you cut EN10219 DN500 LSAW pipe to custom length?
A: Yes, cut-to-length service and pipe end beveling are available to match site welding requirements.
