Tianjin Brisk Metalwork Co., Ltd. is one of the leading manufacturers and suppliers of electric resistance welded hollow section in China. We have world-leading production equipment and strong manufacturing capabilities. Please feel free to buy bulk durable electric resistance welded hollow section from our factory.
PRODUCT
Tianjin Brisk Steel focus on produce and supply hollow section and steel pipe
What Electric Resistance Welded Hollow Sections Do We Produce?
| Item | ERW Production Range |
|---|---|
| Profiles | SHS, RHS, CHS |
| Square size | 20 x 20 mm to 500 x 500 mm |
| Rectangular size | 20 x 10 mm to 600 x 400 mm |
| Round OD | 21.3 mm to 630 mm |
| Wall thickness | 1.2 mm to 16 mm (varies with section size) |
| Standard lengths | 6 m and 12 m, cut-to-length on request |
| Specifications | EN 10219, ASTM A500, AS/NZS 1163, JIS G3466 |
| Finishes | Black, oiled, painted, hot-dip galvanized |
Where Does ERW Fit, and Where Do We Recommend Another Route?
We tell buyers straight: ERW is the most economical route for most building, framing and machinery sections, but it has a ceiling. When a section needs a wall above roughly 16 mm, or a size above the ranges shown, we quote submerged-arc welded or hot-finished sections instead of stretching ERW past what it does best. You get the right product for the load, not the product our mill happens to run.
How Does Coil Become a Hollow Section on Our ERW Lines?
The mechanics explain why ERW is fast and consistent:
- Strip width equals section perimeter. We slit each coil to the exact width for the target profile, so wall thickness comes straight from the coil gauge rather than from additional plate work.
- Continuous forming. The strip is roll-formed into a round tube, welded, then sized. Square and rectangular profiles are formed from that tube in the same line, so there is no separate section-making step.
- High throughput. A running mill turns out finished 6 m and 12 m bars around the clock, which is why repeat orders of one size can be scheduled tightly.
- Heat-number traceability. Every bundle traces back to its coil, so any question about chemistry or mechanical properties leads to a single mill certificate.
Will Every Delivery Match the Last One?
Repeat buyers ask this before anything else, and it is where ERW pays off. Because tube geometry is fixed by the strip and the forming rolls, the same size delivers the same profile shipment after shipment. We check the following on every lot:
- Wall thickness at multiple points on the section, not a single reading
- Weight per meter against theoretical weight, which is what you are billed on
- Straightness and twist on full-length bars
- Corner radius and face flatness on SHS and RHS
- End squareness on cut bars
Steel sold by weight is only as good as its wall thickness, so we treat this as a commercial control as much as a technical one.
Case: How Did an Importer Stop Losing Weight on Repeat Shipments?
A distributor in the Middle East imported 480 tonnes of 100 x 100 x 4 mm SHS across three shipments. On a previous supplier's order, the actual weight of a 6 m bar had run about 3.1% under theoretical, leaving them paying for roughly 15 tonnes of steel that never arrived.
On our order, we checked wall thickness and bar weight lot by lot against theoretical values. The variance came in under 1%, about 4.8 tonnes across the whole 480 tonnes. That difference stayed on the distributor's margin, and the second and third shipments matched the first, so their stock racks were interchangeable.
Which Finishes and Services Can We Add?
- Black or oiled: for stockists and workshops that paint or coat locally
- Primed or painted: in your specified color, ready for site erection
- Hot-dip galvanized: for outdoor frames, greenhouses, solar structures and coastal sites
- Cut, drill, notch and cap: to shorten your fabrication time
Which Applications Use Our ERW Hollow Sections?
- Steel-frame buildings, sheds and mezzanines
- Greenhouse, solar mounting and agricultural frames
- Fencing, gates, handrails and balustrades
- Truck bodies, trailers and machinery frames
- Furniture, racks, shelving and display structures
Frequently Asked Questions (FAQ)
Q: Is ERW the same as HFW?
A: The two names are often used interchangeably in trade. Both describe a hollow section welded by electrical heating and pressure without filler. If your specification names one, tell us and we will confirm it against your drawing.
Q: What is the thickest wall you can make by ERW?
A: Around 16 mm, depending on section size. Above that, we offer other routes.
Q: Can ERW hollow sections be hot-dip galvanized?
A: Yes. We supply galvanized sections for outdoor structures, with vent and drain details agreed with your requirements.
Q: What is your minimum order quantity?
A: It depends on the size and grade. Send us your list and we will confirm what fits a container and what can be combined.
