Tianjin Brisk Steel is one of the manufacturers of EN 10219 S235JRH SQUARE STEEL TUBE in China. Our products are mainly exported to the Middle East, Southeast Asia, Europe, New Zealand, and other regions.If you would like to learn more about our products, feel free to contact us and send your purchase list.
PRODUCT
Tianjin BRISK STEEL focus on produce and supply hollow section and steel pipe
Product Standard & Material Property
- Execution Standard: EN 10219 (Cold formed welded structural steel hollow sections)
- Grade: S235JRH
- S235JRH is a common structural steel grade in European standards. It features low carbon content, good bending, welding and forming performance, no brittle fracture at normal temperature, and strong environmental adaptability. The material meets EU structural steel safety standards, fully compliant for export to European and global markets.
|
Mechanical properties of non-alloy steel hollow sections in thicknesses ≤ 40 mm |
||||||||
| Steel name |
Minimum yield strength ReH MPa |
Tensile strength Rm MPa |
Minimum elongation A d % |
Minimum impact energy KV e J |
||||
|
Specified thickness mm |
Specified thickness mm |
Specified thickness mm |
at test temperature of | |||||
| ≤ 16 | >16 ≤ 40 | ＜3 | ≥ 3 ≤ 40 | ≤ 40 | -20 ℃ | 0 ℃ | 20 ℃ | |
| S235JRH a | 235 | 225 | 360 – 510 | 360 – 510 | 24 b | - | - | 27 |
Available Specifications
We provide customized sizes covering conventional square, rectangular and round S235JRH steel tubes:
- Round tube: Outer diameter 21.3mm - 610mm, wall thickness 1.5mm - 120mm
- Square tube: Size 20*20mm - 1200*1200mm, wall thickness 1.5mm - 50mm
- Rectangular tube: Size 30*20mm - 1000*1500mm, wall thickness 1.5mm - 50mm
- Custom length, cutting, galvanizing, surface polishing processing are available
Key Features
-
Strictly comply with EN 10219 standard, certified for export
-
Excellent structural rigidity and pressure resistance
-
Superior weldability and machinability for secondary processing
-
Corrosion resistance optional with hot-dip galvanized treatment
-
Uniform wall thickness, smooth surface, no cracks, no burrs
-
Factory direct supply, sufficient stock, fast delivery
Application Fields
- EN 10219 S235JRH steel tubes are extensively applied in building steel structures, construction framework, fence engineering, mechanical equipment manufacturing, container accessories, pipeline support structures, stadium and bridge auxiliary structures, and other industrial and construction scenarios.
Contact Us
For more details about EN 10219 S355J0H square hollow sections (price, inventory, customization), please contact us immediately. We will reply to you within 24 hours and provide the best quotation and service! !! We look forward to establishing long-term cooperative relationships with you!
