Tianjin Brisk Metalwork Co.,Ltd is one of the manufacturers of EN 39 HOT DIP GALVANIZED SCAFFOLDING PIPE in China. Our products are mainly exported to the Middle East, Southeast Asia, Europe, New Zealand, and other regions.If you would like to learn more about our products, feel free to contact us and send your purchase list.

PRODUCTION

Chemical Composition And Mechanical Properties

Steel Grade		Chemical Composition %						Mechanical Properties
Steel Grade		C	Si	Mn	P	S	Al	Yield Strength ReH min	Tensile Strength Rm	Elongation A min
Steel Name	Steel Number	max		max	max	max	min	Mpa	Mpa	%
S235GT	1.0106	0.20	a,b	1.40	0.040	0.045	0.020	235	340-520	24
a ＜0.05 % (range 1)(≤0.04 % if option 2 is specified) or ≥0.15 % ≤0.25 % (range 2) b When bare tubes are specified (see option 8) the range shall be reported at the time of enguiry and order.

Demension Tolerance

The specified outside diameter is 48.3 mm and the specified wall thickness is 3.2 mm for type 3 and 4.0 mm for type 4
Tolerances on dimensions
The tolerance on specified outside diameter is +/-0.5 mm.
The tolerance on out of roundness is included in the diameter tolerance.
The tueraire o yal tiuckires -10% However, for seamless tubes,a deviation from specified wall thickness of more than 10% bur no more than 15% of the specified thickness may occur in smooth transition areas over no more than 25% of circumference.
The inside diameter of tubes shall allow insertion of a gauge of diameter 37.7 mm for a minimum length of 200 mm

Applicant Field

S235GT: S = structural steel, 235 = minimum yield strength (MPa), G = for scaffolding use, T = heat treatment condition (normalizing / controlled rolling).
Manufacturing process: ERW resistance welding, surface commonly hot-dip galvanized for corrosion protection.
Application: Construction scaffolding, support frames, temporary structures conforming to EN 39.
