Tianjin Brisk Steel is one of the manufacturers of API 5L line pipe / oil & gas transmission pipe / hydrocarbon pipeline steel tube in China. Our products are mainly exported to the Middle East, Southeast Asia, Europe, New Zealand, and other regions.If you would like to learn more about our products, feel free to contact us and send your purchase list.
Three Main Manufacturing Types
| Type | Full Name | OD Range | Core Advantage | Typical Application |
|---|---|---|---|---|
| SMLS | Seamless Pipe | 1/2"–36" | Zero weld seam, highest pressure resistance | High-pressure gathering lines, sour gas service |
| ERW | Electric Resistance Welded | 2"–24" | Low cost, stable dimensional tolerance | City gas distribution, medium-pressure trunk lines |
| LSAW/DSAW | Longitudinal/Double Submerged Arc Welded | 16"–56" | Ultra-large diameter, heavy wall | Cross-country long-distance oil & gas main pipelines, offshore projects |
Core Steel Grades (Yield Strength Marking Rule: X=ksi minimum yield strength)
Two naming systems: X-series (imperial) / L-series (metric)
| Grade | Min Yield Strength | Main Scenario |
|---|---|---|
| Gr.B / L245 | 245MPa (35ksi) | Low-pressure urban gas, short gathering lines |
| X42 / L290 | 290MPa (42ksi) | Onshore general oil & gas collection pipes |
| X52 / L360 | 360MPa (52ksi) | Most widely used medium-pressure trunk pipelines |
| X60 / L415 | 415MPa (60ksi) | Long-distance high-volume transmission lines |
| X65 / L450 | 450MPa (65ksi) | High-pressure land pipeline |
| X70 / L485 | 485MPa (70ksi) | Main grade for national long-distance oil/gas trunk lines |
| X80 / L555 | 555MPa (80ksi) | Ultra-high pressure deep burial & offshore pipelines |
Critical Classification: PSL 1 vs PSL 2 (Product Specification Level)
PSL1 (Standard Grade)
- Basic chemical composition & mechanical test only
- No mandatory Charpy impact test for regular grades
- For general land low/medium-pressure pipelines, ordinary non-critical projects
- Lower cost, short delivery cycle
PSL2 (High-Strict Premium Grade, Global Major Project Mandatory)
- Tighter control of carbon, sulfur, phosphorus chemical limits
- 100% Charpy V-notch low-temperature impact test
- Full NDT (UT, Eddy Current, Hydrostatic Test for every pipe)
- Strict dimensional & wall thickness tolerance
- Required for offshore, sour H₂S gas, deep burial, high-pressure main pipelines, international bidding projects
Surface Anti-Corrosion Options for Export
- Bare black varnish: Short-term sea transit anti-rust, low cost
- 3LPE / 3PP external coating: Buried long pipeline standard anti-corrosion (80–300μm thickness)
- FBE fusion bonded epoxy: Single-layer anti-corrosion for desert & coastal salt areas
- Internal epoxy coating: Reduce fluid friction, prevent inner corrosion
- Pipe end protection: Blue/red plastic caps to protect welding bevel during shipment
Surface Treatment
Main Application Fields
- Upstream: Oil well gathering lines, gas well flow lines, water injection pipes
- Midstream: Cross-country long-distance crude oil & natural gas transmission trunk lines, offshore subsea pipelines
- Downstream: City municipal natural gas network, refinery process pipeline, fuel transportation pipelines
- Special service: Sour gas pipeline (H₂S medium, comply with API 5L Annex H), low-temperature arctic pipeline, offshore platform piping
FAQ
Q: What's the difference between API 5L and ASTM A106?
A: A106 seamless pipe is for high-temperature steam/heat equipment; API 5L is specially designed for long-distance pressurized oil & gas fluid transmission, with stricter toughness and weldability standards for field pipeline construction.
Q: Do you supply PSL2 X70 LSAW pipe for overseas trunk line projects?
A: Brisk Steel full stock covers Gr.B~X80, both PSL1 & PSL2, complete SMLS/ERW/LSAW production lines, fully pass third-party SGS/BV inspection, meet Saudi, Turkey, Poland, New Zealand project standards, MOQ 25 tons.
Q: What testing do all API 5L pipes undergo?
A: 100% hydrostatic pressure test; online ultrasonic weld inspection for welded pipes; chemical composition analysis; tensile test; PSL2 orders add full low-temperature impact test.
Q: Can we provide custom wall thickness & anti-corrosion coating?
A: Custom OD, WT, length (6m/12m random length or fixed cut length) available; support 3LPE, FBE, internal epoxy coating as per client project drawing requirements.
